CL5890-B08/A08 120kW Integrated DC EVSE
This product is designed for DC fast charging of electric vehicles, with rated output power of 60~120kW and voltage output of 200~1000VDC. One or two DC charging guns (CCS2/CCS1) are designed for charging. When the two guns are charged at the same time, the power of the whole machine is equally divided; Single gun charging can use all the power of the whole machine, with good charging efficiency, and can be applied to a variety of charging scenarios.
Simultaneously 2 DC charging
Double-gun intelligent power distribution function, distribution on demand
The hard ware-level switch interlock monitoring and protection function
Wide voltage constant power output between: 300~1000VDC
Support smart charging and load balancing
10-inch LCD touch color screen
Temperature control fan speed, lower noise, lower power consumption
The charging module adopts the glue filling process and has a longer service life
OTA upgrade, Dialog and Troubleshooting
Applications
Designed for EV bus station, highway gas/service station, parking gargae, EV dealer workshops, commercial fleet operators, EV infrastructure operators and service providers.
Technicla Specifications
Parameters | Model | CL5890-B08C /CL5890-B08B | CL5890-A08C /CL5890-A08B |
Input | Rated voltage | 400 V±15% | |
Input cable | 3P+N+PE | ||
Frequency | 50/60Hz | ||
Output | Output voltage | 150~1000VDC | |
Maximum current | 200 A*2 | 200A | |
Rate power | 60kW/100kW/120kW | ||
Charge connector | CCS1/CCS2,(Dual plug) | CCS1/CCS2,(Single plug) | |
User interface | Enclosure | Galvanized | |
LED indicator | Green/Yellow/Red | ||
LCD display | 10'' color touch screen | ||
RFID reader | Non-contact (ISO/IEC14443 A) | ||
Start mode | QR-code/ Card/ Password | ||
Emergency stop | Yes | ||
Communication | Interface | Ethernet;WIFI/4G(Optional) | |
Protocol | OCPP1.6J/2.0J(Optional) | ||
Electrical performance | Efficiency | ≥95%（Half load and above） | |
Power factor | ≥0.98 @ 50%~100% loading | ||
THD | ≤5% @ 50%~100% loading | ||
Ripple factor | ≤±0.5% | ||
Safety | Energy meter | DC Meter, Accuracy 1.0 | |
Protection grade | IP54/IK10 | ||
Electrical protection | Over current protection,Residual current protection,Short circuit protection,Ground protection,Surge protection,Over/Under voltage protection,Over temperature protection | ||
Certification | CE; KC(100kW) | ||
Standard | EN/IEC 61851-1,EN/IEC 61851-23,IEC 61851-24,EN/IEC 61851-21-1 | ||
Work Environment | Cooling method | Forced Fan cooling | |
Installation | Floor mounted | ||
Temperature | -25℃~﹢50℃ | ||
Humidity | 5%～95% (Non-condensation) | ||
Altitude | ≤2000m | ||
Package | Product size | 800（W）*750（D）×1,600（H）mm | |
Package size | 1120(W)*900(D)*1800 (H) mm | ||
N.W. | 360kg（no module） | ||
